Default Goodies for the Park Ave. FWI, FIE, and Gen 3

well, i went through with my Gen 3 swap on my buick.

following wren'* recipe, the coating turned out pretty good.




my FWI setup


Flow matched injectors. 0% spread, yeah baby! thank you Spud @ FIE, and Jimmy Floyd both. i wouldn't have had 0% spread without JF'* injector pool.


i smudged the coating a little before it fully cured :(
Name:  100_2345.jpg
Views: 0
Size:  100.6 KB
Name:  100_2340.jpg
Views: 0
Size:  114.2 KB
Name:  100_2343.jpg
Views: 0
Size:  119.1 KB

and i will have to wait for the sun to move to get some better pics, but hey
Name:  100_2341.jpg
Views: 0
Size:  92.7 KB
Name:  100_2342.jpg
Views: 0
Size:  89.3 KB


this was fairly painless. i had a problem with it running lean bc of the tb having no screen. looking at Bill'* chart in his tb thread, i realized that the 94-95 L67 TB ID is very close to a L36 TB. so i tried it, and the screens interchange very well. i was suprised at how much of a difference that screen will make. A piece of advise for most of us here, is to NEVER remove that screen.
