Transmission question - GM Forum - Buick, Cadillac, Chev, Olds, GMC & Pontiac chat


Performance, Brainstorming & Tuning Talk about modifications, or anything else associated with performance enhancements. Have a new idea for performance/reliability? Post it here. No idea is stupid! (please use Detailing and Appearance for cosmetic ideas)

Reply



Thread Tools Search this Thread
Old 12-16-2005, 08:55 PM   #1
Senior Member
Certified GM nut
Thread Starter

Join Date: Sep 2005
Location: Home Sweet Home in New York
Posts: 2,009
Thanks: 0
Thanked 0 Times in 0 Posts
Mortehl is on a distinguished road
Default Transmission question

Would the 4T60-E heavy duty transmission benefit from a limited slip differential? Been reading about them and it looks good, but I was wondering if we'd benefit from it?
Mortehl is offline   Reply With Quote
Old 12-16-2005, 09:24 PM   #2
Senior Member
Certified Car Nut

Join Date: Oct 2003
Posts: 19,756
Thanks: 0
Thanked 0 Times in 0 Posts
1993 SLE is on a distinguished road
Default

yes, the car will not do one wheel wonders
1993 SLE is offline   Reply With Quote
Old 12-16-2005, 11:17 PM   #3
Senior Member
Expert Gearhead

Join Date: Dec 2002
Location: Mississauga, Ontario
Posts: 20,892
Thanks: 0
Thanked 1 Time in 1 Post
Jim W is on a distinguished road
Default

Talk to Rogue (Todd Allen), an LSD is one of the best things you can do for a tranny. Uniform wheel spin is good stuff. When doing a burnout or even a light chirp off the line, you want the tires to spin at the same rate.
Jim W is offline   Reply With Quote
Old 12-16-2005, 11:43 PM   #4
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Ask yourself when the last time you did a one-wheel-wonder in a straight line was.

Every car in good condition on this Forum will lay twins in a straight line, both of mine included, and yours too.

Now balance that fact against the cost of an LSD for your car.

That enormous chunk of money will buy alot of other mods.

An LSD is for a HARDCORE track hound or roadcourse driver.
willwren is offline   Reply With Quote
Old 12-17-2005, 12:25 AM   #5
Senior Member
Certified Car Nut

Join Date: Oct 2003
Posts: 19,756
Thanks: 0
Thanked 0 Times in 0 Posts
1993 SLE is on a distinguished road
Default

Quote:
Originally Posted by willwren

Every car in good condition on this Forum will lay twins in a straight line, both of mine included, and yours too.
no problems here

Name:  10-16newintake023.jpg
Views: 0
Size:  71.7 KB
1993 SLE is offline   Reply With Quote
Old 12-17-2005, 02:50 AM   #6
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Exactly my point. For most of us, it'll make no difference. For a very few, that little extra edge is worth pursuing.

I had my diff rebuilt HD rather than LSD.
willwren is offline   Reply With Quote
Old 12-17-2005, 05:06 AM   #7
Senior Member
Posts like a Supercharger

Join Date: Dec 2005
Location: Ohio
Posts: 171
Thanks: 0
Thanked 0 Times in 0 Posts
GTPboy is on a distinguished road
Default

all I have to say is the stocker can run 9s, if done correctly.

And an LSD does nothing if not used correctly. Less failures with stock (if driven right)
and a whole lot more failures with an LSD.

*FYI-I have used an Intense and a c-ya. both destroyed themselves. and I have YET to break a stocker (knock on wood).With over 400 passes using stock diffs.
GTPboy is offline   Reply With Quote
Old 12-17-2005, 10:07 AM   #8
Senior Member
True Car Nut

Join Date: Jul 2003
Location: Westerville, Ohio 2000 Black SSEi
Posts: 6,127
Thanks: 0
Thanked 0 Times in 0 Posts
Rogue is on a distinguished road
Default

Even if you manage to get 2 black lines on a street burnout with a stock dif, the rate at which the tires are spinning is usually not the same. If anyone has ever gotten hard on a GTP or SSEi with power you probably notice the car shift left then right. This is torque steer because power is being applied unevenly (more power to one side, then the other). An LSD virtually eliminates torque steer as well as makes sure during a burnout that both tires are not only spinning, but at the same rate.

Even during a two wheel burnout if the tires are spinning at a different rate then scoring can occur on the pinion shaft. Eventually this will lock the pinion shaft to the spider gear causing a dramatic failure. If the stock differential was so great, GM wouldn't have come out with their torsen designed racing differential very similar to the Quaife. And for those who are not in the know both the quaife and the GM version of the differential have been failing left and right.

Right now there is no perfect solution for the differential problem. INTENSE hopes to address as many of the shortcomings as possible while maintaining high reliability. We have been designing, testing and redesigning our Gen III for almost 10 months now and we are very close to a release. The Gen III has a completely different design team from the first two releases and for the price point it WILL be the best available option.
Rogue is offline   Reply With Quote
Old 12-17-2005, 11:50 AM   #9
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

Bottom line..

Aaron.. you can do it..but you won't need it.
BillBoost37 is offline   Reply With Quote
Old 12-17-2005, 12:48 PM   #10
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

I may be wrong here, but my understanding is that torque steer is primarily cause by the different length/angle of the drive axles due to the configuration of the trans under the car.

The more even or alike they are on other cars, the less torque steer.

If the rate of burn is different, it can't be by much. I can't tell the difference between my twins, and just laid a good 50' in Portland a few days ago. Both tires.

The long and the short of it is that it doesn't typically buy you much in terms of ET. The hardcore track hounds may need that little extra, but I seriously doubt it'* the .1 off the 60' that some mention. I watched two identically modded cars this year at the track, one with and one without an LSD. There was no edge to be seen.
willwren is offline   Reply With Quote
