Default replacement UIM from APN come with EGR tube sleeve?

does the replacement UIM from APN come with EGR tube sleeve....is that EGR tube also called the stovepipe..i'm still learning? anyway i need to order my UIM ASAP so i can put my ride back together..let me know
showshocka2k is offline   Reply With Quote
Old 03-15-2007, 10:41 AM   #2
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

The APN does have a sleeved EGR area and yes the tube is called a stovepipe. Not sure if the APN kit comes with the pipes, I think it does.

Bill Buttermore or Bob Dillion will be along soon.. They've got you covered.
BillBoost37 is offline   Reply With Quote
Old 03-15-2007, 10:46 AM   #3
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Feb 2007
Location: Baltimore City, Maryland
Posts: 100
Thanks: 0
Thanked 0 Times in 0 Posts
showshocka2k is on a distinguished road
Default

i need to order it like now but their not open yet and they dont really make it too clear that the stovepipe comes with it.....anybody else?
showshocka2k is offline   Reply With Quote
Old 03-15-2007, 10:54 AM   #4
Senior Member
True Car Nut

Join Date: Mar 2004
Location: Ames, Iowa
Posts: 3,066
Thanks: 0
Thanked 1 Time in 1 Post
bill buttermore is on a distinguished road
Default

Yes, the APN kit comes with a sleeved EGR passage and a reduced diameter stovepipe that will replace the larger stainless steel stovepipe that came stock in your car. I'll find you a picture of the APN pipe and sleeve. (Goes to get pic...)
bill buttermore is offline   Reply With Quote
Old 03-15-2007, 10:55 AM   #5
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

And there'* Mr. Buttermore...right on cue.
BillBoost37 is offline   Reply With Quote
Old 03-15-2007, 11:01 AM   #6
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Feb 2007
Location: Baltimore City, Maryland
Posts: 100
Thanks: 0
Thanked 0 Times in 0 Posts
showshocka2k is on a distinguished road
Default

showshock.....<------waits patiently
showshocka2k is offline   Reply With Quote
Old 03-15-2007, 11:11 AM   #7
Senior Member
True Car Nut

Join Date: Mar 2004
Location: Ames, Iowa
Posts: 3,066
Thanks: 0
Thanked 1 Time in 1 Post
bill buttermore is on a distinguished road
Default

Here is a photo of an APN sleeve and pipe. (Thanks, Arbelac.) The APN pipe has a .505" body and a .749" base that will fit right into the LIM of 95-98 L36 engines like yours. Name:  APNarbelac.jpg
Views: 7
Size:  96.4 KB
