Default How to make a real cold air intake using your stock airbox!

First of all, you can either buy a short ram intake or use your stock air filter, i bought a -"cold air intake" off of ebay. It is just a chrome elbow piece with a cone filter on the end of it.

The first thing you need to do is completely gut you restrictive stock air box. do this by removing the whole airbox, then take the front half and cut out the inside piece(use a wire cutters to cut out the plastic notches along the edges)then cut out the front of the airbox where the stock hole was,do not expose radiater hose..., also cut out the side closest to the computor. I used a dremel. The rear part of the box is the easiest, all you have to do is use a wire cutters to cut the plastic notches that go along the inside of the box, then the whole inside will fall right out and your airbox is now completely gutted.

now cut away some of the insolation next to your computor to match the side section you cut out...., now this is the part where you can either get a different intake tube and cone filter, or replace stock square filter. if you decide to use an aftermarket intake tube and cone filter then but it all on and put the airbox on over it. i garuntee you will notice a improvment, just ask insane Lss, i did this on his car also. do not forget to reconnect the air temperature sensor(aftermarket elbows should have a hole). hopefully today i will have some pictures but i do not have a digital camera, so blownbuick is going to take pictures of my intake to show you... [/img]
FattyAzzBonneville is offline   Reply With Quote
Old 06-22-2006, 02:58 PM   #2
Senior Member
True Car Nut

Join Date: Jun 2004
Location: Rochester, NY (college)
Posts: 6,182
Thanks: 0
Thanked 0 Times in 0 Posts
corvettecrazy is on a distinguished road
Default



words are great, but a picture is worth a 1000 of them
corvettecrazy is offline   Reply With Quote
Old 06-22-2006, 03:35 PM   #3
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Sounds very similar or identical to what a few members here have already done. Seems to work well, but the best thing you can do at this point is get rid of the stock accordian tube and find something that flows a bit smoother.
willwren is offline   Reply With Quote
Old 06-22-2006, 03:44 PM   #4
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Jun 2006
Location: palatine, illinois
Posts: 124
Thanks: 0
Thanked 0 Times in 0 Posts
FattyAzzBonneville is on a distinguished road
Default

yeah, i want to get pictures hopefully today, but i have the elbow piece coming off of my throttle body through the stock air box and connecting to my cone filter. also, can you tell me how to post a picture, i tried copying but it wont let me paste in the text box
FattyAzzBonneville is offline   Reply With Quote
Old 06-22-2006, 04:05 PM   #5
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Host your picture on www.photobucket.com and link to it here using the img tags.

You cannot cut and paste.

If you need help with posting and hosting pics, please use the lounge instead of this technical section of the Forum.
willwren is offline   Reply With Quote
Old 06-22-2006, 04:25 PM   #6
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Jun 2006
Location: palatine, illinois
Posts: 124
Thanks: 0
Thanked 0 Times in 0 Posts
FattyAzzBonneville is on a distinguished road
Default

thnakyou, i used photobucket, i am going outside to take some pictures of my intake, in the meantime, check out me and insane lss'* supercharged six symbol.....http://s62.photobucket.com/albums/h9...t=000_0149.jpg
FattyAzzBonneville is offline   Reply With Quote
Old 06-22-2006, 04:53 PM   #7
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Jun 2006
Location: palatine, illinois
Posts: 124
Thanks: 0
Thanked 0 Times in 0 Posts
FattyAzzBonneville is on a distinguished road
Default

thanks for putting that up there for us, do you put the image tag before or after the web adress
FattyAzzBonneville is offline   Reply With Quote
Old 06-22-2006, 05:08 PM   #8
Senior Member
True Car Nut

Join Date: May 2005
Location: _Phoenix, AZ_ _WCBF '05, '06, '07 Survivor_ ____NEBF '07 Remnant___
Posts: 3,448
Thanks: 0
Thanked 0 Times in 0 Posts
Echo SSEI is on a distinguished road
Default

Quote:
Originally Posted by FattyAzzBonneville
thanks for putting that up there for us, do you put the image tag before or after the web adress
Put [img] before..then [/img] after.
Echo SSEI is offline   Reply With Quote
Old 06-22-2006, 05:26 PM   #9
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Quote:
Originally Posted by willwren

If you need help with posting and hosting pics, please use the lounge instead of this technical section of the Forum.
willwren is offline   Reply With Quote
Old 06-22-2006, 05:26 PM   #10
Senior Member
Posts like a 4 Banger
Thread Starter

Join Date: Jun 2006
Location: palatine, illinois
Posts: 124
Thanks: 0
Thanked 0 Times in 0 Posts
FattyAzzBonneville is on a distinguished road
Default

here are some pics of my car and intake, it was soo hard to put the short ram inside of the stock airbox and i didnt want to take it off again so this is all i have so farName:  000_0156.jpg
Views: 1
Size:  105.7 KB
[img]ttp://i62.photobuckhet.com/albums/h98/fattyazzbonneville/000_0157.jpg[/img]

Name:  000_0169.jpg
Views: 1
Size:  122.6 KB
Name:  000_0170.jpg
Views: 1
Size:  124.5 KB
