ok 100% it is not the fly wheel. While it was making the noise I pulled the oil dipstick, and for the some reason the dipstick had a vacuum, and the noise immediately stopped. I put the dipstick back in for and let it run for a little while and the noise is back. I pull it and it disappears again. Some sort of crank case breather issue then? I'm so confused now.
buffstuffbuddha is offline   Reply With Quote
Old 09-01-2011, 10:19 PM   #23
Retired Senior Admin

Expert Gearhead

Danthurs's Avatar

Join Date: May 2006
Location: Sheboygan Wisconsin
Posts: 29,661
Thanks: 0
Thanked 16 Times in 13 Posts
Danthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to all
Default

PCV valve
Danthurs is offline   Reply With Quote
Old 09-01-2011, 10:39 PM   #24
Member
Posts like a V-Tak
Thread Starter

Join Date: Oct 2007
Location: Cleveland, OH
Posts: 80
Thanks: 0
Thanked 0 Times in 0 Posts
buffstuffbuddha is on a distinguished road
Default

My intake doesn't have an actual valve. It has a plate that says pcv on it and when I take that off there is a spring under it. ?
buffstuffbuddha is offline   Reply With Quote
Old 09-01-2011, 10:40 PM   #25
Member
Posts like a V-Tak
Thread Starter

Join Date: Oct 2007
Location: Cleveland, OH
Posts: 80
Thanks: 0
Thanked 0 Times in 0 Posts
buffstuffbuddha is on a distinguished road
Default

Attached Thumbnails
Crankshaft Bearing 2002 SSEi-090111212427.jpg
buffstuffbuddha is offline   Reply With Quote
Old 09-01-2011, 10:41 PM   #26
Retired Senior Admin

Expert Gearhead

Danthurs's Avatar

Join Date: May 2006
Location: Sheboygan Wisconsin
Posts: 29,661
Thanks: 0
Thanked 16 Times in 13 Posts
Danthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to all
Default

And under that spring is your PCV valve.
Danthurs is offline   Reply With Quote
Old 09-01-2011, 10:44 PM   #27
Member
Posts like a V-Tak
Thread Starter

Join Date: Oct 2007
Location: Cleveland, OH
Posts: 80
Thanks: 0
Thanked 0 Times in 0 Posts
buffstuffbuddha is on a distinguished road
Default

ah, sorry I feel kinda dumb now. So you think that is the problem? How does it come out once I pull the spring? Is it just sitting in there?
buffstuffbuddha is offline   Reply With Quote
Old 09-01-2011, 10:48 PM   #28
Retired Senior Admin

Expert Gearhead

Danthurs's Avatar

Join Date: May 2006
Location: Sheboygan Wisconsin
Posts: 29,661
Thanks: 0
Thanked 16 Times in 13 Posts
Danthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to allDanthurs is a name known to all
Default

A needle nose pliers and it will come right out. If the O ring is gone it will make cause a vacuum in the crank case. Only other possibility is a bad gasket between the LIM and supercharger and it'* leaking from the intake to the PCV valve.
Danthurs is offline   Reply With Quote
Old 09-01-2011, 10:50 PM   #29
Member
Posts like a V-Tak
Thread Starter

Join Date: Oct 2007
Location: Cleveland, OH
Posts: 80
Thanks: 0
Thanked 0 Times in 0 Posts
buffstuffbuddha is on a distinguished road
Default

Even tho I swapped all my stuff onto this motor (oil filter bracket, oil pan, and the funnel inside the oil pan, intake and supercharger, and a bunch of the accessories, is there any way that the LIM would be different and could be causing this problem? They looked the same but I'm a bit of a hypochondriac when it comes to these things. The only reason I ask is because the reason I used my intake is because the one on the motor had the vacuum lines run a little differently as well as one of the plugs on the wiring harness.
buffstuffbuddha is offline   Reply With Quote
Old 09-01-2011, 10:53 PM   #30
Member
Posts like a V-Tak
Thread Starter

Join Date: Oct 2007
Location: Cleveland, OH
Posts: 80
Thanks: 0
Thanked 0 Times in 0 Posts
buffstuffbuddha is on a distinguished road
Default

I replaced the intake manifold gasket as well as the o rings when I swapped everything so the gasket can't be bad. Should there be oil when I pull that cover for the pcv valve? I coulda sworn there was oil on the spring.
