TCC and Overdrive Questions - Page 2 - GM Forum - Buick, Cadillac, Chev, Olds, GMC & Pontiac chat


1992-1999 Series I L27 (1992-1994 SE,SLE, SSE) & Series II L36 (1995-1999 SE, SSE, SLE) and common problems for the Series I and II L67 (all supercharged models 92-99) Including Olds 88's, Olds LSS's and Buick Lesabres Please use General Chat for non-mechanical issues, and Performance and Brainstorming for improvements.

Reply



Thread Tools Search this Thread
Old 03-16-2006, 12:33 PM   #11
BANNED

Join Date: Aug 2002
Posts: 0
Thanks: 0
Thanked 0 Times in 0 Posts
banned3800 is on a distinguished road
Default

Quote:
Originally Posted by 1993 SLE
Quote:
Originally Posted by BillBoost37

<~~~ calling to wake up an fsm owner


i can give you the paramaters that need to be met for TCC in 3rd and 4th
Go ahead and post them...

__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
banned3800 is offline   Reply With Quote
Old 03-16-2006, 12:41 PM   #12
Senior Member
Posts like a Turbo
Thread Starter

Join Date: Feb 2006
Posts: 220
Thanks: 0
Thanked 0 Times in 0 Posts
NCCamper is on a distinguished road
Default

Yes...please post them! I am very interested to find out what the params are.

Thanks,
John
NCCamper is offline   Reply With Quote
Old 03-16-2006, 12:55 PM   #13
Senior Member
True Car Nut

Join Date: Oct 2005
Location: Central Florida
Posts: 7,030
Thanks: 0
Thanked 0 Times in 0 Posts
lash is on a distinguished road
Default

While we're waiting for Pat to wake back up, I just wanted to say that I think the $750 you paid is reasonable for the work you had done. I know that some of us paid a LOT more for similar work (once).
lash is offline   Reply With Quote
Old 03-16-2006, 01:05 PM   #14
Senior Member
Certified Car Nut

Join Date: Oct 2003
Posts: 19,756
Thanks: 0
Thanked 0 Times in 0 Posts
1993 SLE is on a distinguished road
Default

While i have the FSM TCC pages scanned...........PB is currently down for Maint, and will post as soon as i can get the pics loaded
1993 SLE is offline   Reply With Quote
Old 03-16-2006, 01:05 PM   #15
Senior Member
Posts like a Turbo
Thread Starter

Join Date: Feb 2006
Posts: 220
Thanks: 0
Thanked 0 Times in 0 Posts
NCCamper is on a distinguished road
Default

lash ~

Thanks for the input. I thought it was reasonable, too. And the mechanic is a guy who has worked on this Bonne before, and does very good work.4 years ago, when the tranny failed on my (then future) wife, when others were insisting on a total rebuild, he took the car and just worked on 2nd gear, and we havent had an issue in 4 years and 75,000 miles - she paid one fourth of what a rebuild would have cost. BTW, he detailed the engine from the cover to the oil pan, just to make sure I could see if all the "leaks" were taken care of (see my sig line which I may have to change). The 3800 looks brand new!

John
NCCamper is offline   Reply With Quote
Old 03-16-2006, 01:23 PM   #16
Senior Member
Certified Car Nut

Join Date: Oct 2003
Posts: 19,756
Thanks: 0
Thanked 0 Times in 0 Posts
1993 SLE is on a distinguished road
Default

Here are the scans...Im gonna send the Files to Don and he can load them on his unlimited PB acct, so there can be Bigger pics

third gear TCC

Name:  scan002.jpg
Views: 0
Size:  49.3 KB

Fourth gear TCC

Name:  scan003.jpg
Views: 0
Size:  50.6 KB
1993 SLE is offline   Reply With Quote
Old 03-16-2006, 01:24 PM   #17
Senior Member
True Car Nut

Join Date: Oct 2005
Location: Central Florida
Posts: 7,030
Thanks: 0
Thanked 0 Times in 0 Posts
lash is on a distinguished road
Default

Quote:
Originally Posted by NCCamper
lash ~

Thanks for the input. I thought it was reasonable, too. And the mechanic is a guy who has worked on this Bonne before, and does very good work.4 years ago, when the tranny failed on my (then future) wife, when others were insisting on a total rebuild, he took the car and just worked on 2nd gear, and we havent had an issue in 4 years and 75,000 miles - she paid one fourth of what a rebuild would have cost. BTW, he detailed the engine from the cover to the oil pan, just to make sure I could see if all the "leaks" were taken care of (see my sig line which I may have to change). The 3800 looks brand new!

John
Sounds like you have one of the good ones. Don't let him get away, lol.
lash is offline   Reply With Quote
Old 03-16-2006, 01:27 PM   #18
Senior Member
Posts like a Turbo
Thread Starter

Join Date: Feb 2006
Posts: 220
Thanks: 0
Thanked 0 Times in 0 Posts
NCCamper is on a distinguished road
Default

Ok..I just read the scanned info. Thanks for the scan. Now do these things happen in the sequence listed? Because if I am reading correctly (and I may very well not be ) then the TCC lock happens in 3rd gear, and then the shift into 4th happens. In my case (when it'* working right) I see a small drop in RPM (~500) at around 46 MPH on a level road. AT around 52 MPH, there is a larger drop in RPM, such that I run 55 MPH at around 1600 RPM. Of course, all of this is read using the dash gauges and as such there is a margin of error. But, the question is, "am I interpreting these pages correctly?

Thanks,
John
NCCamper is offline   Reply With Quote
