Default Fuel Pump Regulator

1997 Bonneville 3800 series 2.
How does the fuel pump regulator come off of the fuel rail?
Are most GM ignition coils the same, as in buick, chev, olds 3800 series 2?
Replacing TPS that does not have slotted holes for adjustment, so does it just go straight on?
Thanks
flyballdog is offline   Reply With Quote
Old 03-31-2011, 02:11 AM   #2
Senior Member
Certified GM nut

SignOfZeta's Avatar

Join Date: Mar 2005
Location: New Milford, CT
Posts: 2,284
Thanked 16 Times in 13 Posts
SignOfZeta has a spectacular aura aboutSignOfZeta has a spectacular aura about
Default

Quote:
Originally Posted by flyballdog View Post
1997 Bonneville 3800 series 2.
Great car.

Quote:
Originally Posted by flyballdog View Post
How does the fuel pump regulator come off of the fuel rail?
You need to use snap ring pliers after you've depressurized the fuel lines. I hear it just lifts out after that, but I haven't done this myself.

Quote:
Originally Posted by flyballdog View Post
Are most GM ignition coils the same, as in buick, chev, olds 3800 series 2?
Yes. You'll find testing and replacement instructions elsewhere in the forum.

Quote:
Originally Posted by flyballdog View Post
Replacing TPS that does not have slotted holes for adjustment, so does it just go straight on?
As long as you turn it in the correct direction when installing, it'* entirely self-adjusting. At least I've never had to adjust mine.

Quote:
Originally Posted by flyballdog View Post
Thanks
No problem.
SignOfZeta is offline   Reply With Quote
Old 03-31-2011, 07:25 AM   #3
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

Colin pretty much aced that one.

FPR the pliers make it easy. Then pull and wiggle it out.
Coils are different between NA and SC cars. You'll want SC coils. IIRC the color underneath is yellow on the SC'd.
TPS has no adjustment after 95 and it'* a straight bolt on.
BillBoost37 is offline   Reply With Quote
Old 03-31-2011, 08:10 AM   #4
Senior Member
Posts like a Supercharger
Thread Starter

flyballdog's Avatar

Join Date: Aug 2010
Location: Tweed Ontario Canada
Posts: 167
Thanks: 0
Thanked 0 Times in 0 Posts
flyballdog is on a distinguished road
Default

Coils are different between NA and SC cars. You'll want SC coils ?


This is a 97 Bonneville SE. No Super charger.
Attached Thumbnails
Fuel Pump Regulator-p1030190.jpg
flyballdog is offline   Reply With Quote
Old 03-31-2011, 11:31 AM   #5
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

If you are picking up coils though...why not get the better ones?
BillBoost37 is offline   Reply With Quote
Old 03-31-2011, 02:08 PM   #6
Senior Member
Posts like a Supercharger
Thread Starter

flyballdog's Avatar

Join Date: Aug 2010
Location: Tweed Ontario Canada
Posts: 167
Thanks: 0
Thanked 0 Times in 0 Posts
flyballdog is on a distinguished road
Default

So the coils are interchangeable from N/A to Super charged?
flyballdog is offline   Reply With Quote
Old 03-31-2011, 10:11 PM   #7
Administratus Emeritus
Certified Car Nut

GXP Venom's Avatar

Join Date: Jan 2006
Location: Purgatory, Pennsylvania
Posts: 16,538
Thanked 7 Times in 4 Posts
GXP Venom is on a distinguished road
Default

Moved to Mechanical/Bonneville/92-99 for better visibility and search engine indexing.
