Default Duel exhaust outlets on an SE

I read somewhere on here that a V8 Camero muffler would fit a '94 SE.

At least I think I read that, I can't find it.

Anyway I answered an ad for a new magnaflow muffler for a Camero but when I asked he said the inlet was on the passenger side. Is he wrong or is there more than one set up for a Camaro?
JMH1950 is offline   Reply With Quote
Old 01-21-2008, 11:00 PM   #2
Senior Member
Posts like a Supercharger

Join Date: Sep 2007
Location: Zelienople, Pennsylvania
Posts: 166
Thanks: 0
Thanked 0 Times in 0 Posts
White93z34 is on a distinguished road
Default

On my 87' Camaro, the inlet is passengers side for sure.
White93z34 is offline   Reply With Quote
Old 01-21-2008, 11:08 PM   #3
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Flip the muffler over and it'* on the other side. They are crossflow mufflers. Outlet on one end, inlet and outlet on the other end.
willwren is offline   Reply With Quote
Old 01-22-2008, 05:02 PM   #4
Senior Member
Posts like a Northstar
Thread Starter

Join Date: Aug 2007
Location: Ladysmith B.C. Canada
Posts: 620
Thanks: 0
Thanked 0 Times in 0 Posts
JMH1950 is on a distinguished road
Default

Quote:
Originally Posted by willwren
Flip the muffler over and it'* on the other side. They are crossflow mufflers. Outlet on one end, inlet and outlet on the other end.



Why didn't I clue into that?

Now the fun begins, but first I have to pry the car away from the wife for a day.
JMH1950 is offline   Reply With Quote
Old 01-22-2008, 05:13 PM   #5
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

You will need to account for outlets and/or tips to turn to the rear and for the SSEi/SSE exhaust hangers. The hanger brackets are welded to the turned outlets:

Name:  DSC00563.jpg
Views: 7
Size:  45.3 KB
You can just see the sheet metal welded to the outside turn on the outlets, and that connects to the rubber hanger.
willwren is offline   Reply With Quote
Old 01-27-2008, 06:56 PM   #6
Senior Member
Posts like a Northstar
Thread Starter

Join Date: Aug 2007
Location: Ladysmith B.C. Canada
Posts: 620
Thanks: 0
Thanked 0 Times in 0 Posts
JMH1950 is on a distinguished road
Default

I can't quite see what you mean, hopefully I can see it in person in a few weeks.

Got the muffler and tips yesterday, delivered to my door for a total of $30. I was expecting semi to well used but except for a heavy layer of dirt and one slightly damaged tip, it looks brand new. He says it'* been sitting in his garage for 2 years.

This almost complete kit:

Name:  15684_lg_a.jpg
Views: 8
Size:  8.6 KB

Some brackets and hangers are missing as well as the long pipe that I don't need anyway.
JMH1950 is offline   Reply With Quote
Old 01-27-2008, 08:39 PM   #7
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

You'd be best to cut off those hangers and use OEM hangers instead. There'* a couple cars here you can cut off the tips from with my cordless reciprocating saw. You'll need the other half of the bracket anyway.
willwren is offline   Reply With Quote
Old 01-27-2008, 11:47 PM   #8
Junior Member
Posts like a Ricer Type-R

Join Date: Aug 2002
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
willwren is on a distinguished road
Default

Hold the presses!

Just remembered jr's3800 got these from AdvanceAuto part numbers 42569 and 42558 for the left and right, with hanger brackets welded. The description is 'walker pipe'.

25 bucks a side though. Still think a wrecker would be best.
willwren is offline   Reply With Quote
