Default Cracked rubber in the torque strut mount

While under my car for an oil change, I noticed that the rubber in my torque strut mount is badly cracked. (The picture shows how dirty it is, but not the cracked rubber.)

I don't notice any new issues while driving, but because it'* only $9 at RockAuto, I'm thinking I should just replace it. Is it a difficult swap?
Attached Thumbnails
Cracked rubber in the torque strut mount-busted-tranny-mount-001.jpg
SignOfZeta is offline   Reply With Quote
Old 08-03-2010, 03:24 PM   #2
Senior Member
True Car Nut

xtremerevolution's Avatar

Join Date: Jun 2007
Location: New Lenox, IL
Posts: 2,478
Thanks: 0
Thanked 0 Times in 0 Posts
xtremerevolution is on a distinguished road
Default

I would replace it ASAP. Can't tell you how difficult it would be since I've never owned that year Bonneville myself, but a broken mount will put unnecessary stress on the remaining good mounts, and can cause other problems as well due to the excessive engine movement in the engine bay.
xtremerevolution is offline   Reply With Quote
Old 08-03-2010, 03:40 PM   #3
Senior Member
Posts like a Northstar

RobertISaar's Avatar

Join Date: Jul 2010
Location: Camden, MI
Posts: 615
Thanks: 0
Thanked 0 Times in 0 Posts
RobertISaar is on a distinguished road
Default

i've certainly seen worse...

RobertISaar is offline   Reply With Quote
Old 08-03-2010, 03:42 PM   #4
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

The pictured dogbone is held in by two bolts. IIRC they are both 15mm'* or 13mm'*. It'* actually a very easy swap.

Oil and grime will degrade and break down rubber BTW. So it'* a nice thing to keep the engine bay clean.
BillBoost37 is offline   Reply With Quote
Old 08-03-2010, 04:15 PM   #5
Senior Member
Certified GM nut
Thread Starter

SignOfZeta's Avatar

Join Date: Mar 2005
Location: New Milford, CT
Posts: 2,284
Thanked 16 Times in 13 Posts
SignOfZeta has a spectacular aura aboutSignOfZeta has a spectacular aura about
Default

Quote:
Originally Posted by RobertISaar View Post
i've certainly seen worse...
That picture you posted is for a torque axis mount. That one seems to be quite intact and not leaking. The one that'* breaking is the torque strut mount, which is down near the oil filter.

Quote:
Originally Posted by BillBoost37 View Post
The pictured dogbone is held in by two bolts. IIRC they are both 15mm'* or 13mm'*. It'* actually a very easy swap.

Oil and grime will degrade and break down rubber BTW. So it'* a nice thing to keep the engine bay clean.
Not that I don't like visiting you, but is this something I could do on my own (i.e., without an engine lift)?

The top half of my engine gets cleaner every day, thanks to my recent discovery of brake parts cleaner. My transmission case is so shiny now, you'd think I finally replaced it. Bottom half is next on my "I'm bored today" list.
SignOfZeta is offline   Reply With Quote
Old 08-03-2010, 04:21 PM   #6
Senior Member
Posts like a Northstar

RobertISaar's Avatar

Join Date: Jul 2010
Location: Camden, MI
Posts: 615
Thanks: 0
Thanked 0 Times in 0 Posts
RobertISaar is on a distinguished road
Default

odd.... alldata doesn't show any other engine mounts for a bonneville....
RobertISaar is offline   Reply With Quote
Old 08-03-2010, 04:31 PM   #7
Senior Member
Certified GM nut
Thread Starter

SignOfZeta's Avatar

Join Date: Mar 2005
Location: New Milford, CT
Posts: 2,284
Thanked 16 Times in 13 Posts
SignOfZeta has a spectacular aura aboutSignOfZeta has a spectacular aura about
Default

Quote:
Originally Posted by RobertISaar View Post
odd.... alldata doesn't show any other engine mounts for a bonneville....
From what I gathered by reading other threads, it'* this one, Anchor part #2881.
SignOfZeta is offline   Reply With Quote
Old 08-03-2010, 11:57 PM   #8
Senior Member
Posts like a Corvette

Nighthwk12's Avatar

Join Date: Feb 2009
Location: Jersey Shore
Posts: 1,511
Thanks: 0
Thanked 0 Times in 0 Posts
Nighthwk12 is on a distinguished road
Default

It'* very easy to do. Take the two bolts out. Slip it out. Pop the new one in and tighten the bolts.
Nighthwk12 is offline   Reply With Quote
Old 08-04-2010, 01:34 AM   #9
Senior Member
Certified GM nut
Thread Starter

SignOfZeta's Avatar

Join Date: Mar 2005
Location: New Milford, CT
Posts: 2,284
Thanked 16 Times in 13 Posts
SignOfZeta has a spectacular aura aboutSignOfZeta has a spectacular aura about
Default

Quote:
Originally Posted by Nighthwk12 View Post
It'* very easy to do. Take the two bolts out. Slip it out. Pop the new one in and tighten the bolts.
No engine lift or jack needed? I don't want to pull off the old mount, and then need to push up on a quarter-ton of drivetrain to slide the new mount in.
SignOfZeta is offline   Reply With Quote
Old 08-04-2010, 07:26 AM   #10
DINOSAURUS BOOSTUS

Expert Gearhead

BillBoost37's Avatar

Join Date: Mar 2005
Location: Enfield, CT
Posts: 41,391
Thanks: 0
Thanked 0 Times in 0 Posts
BillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of lightBillBoost37 is a glorious beacon of light
Default

Nah.. it'* a two bolt thing. Just like I said.
